Amada HFE M2 5020 Press Brake, 8 axis (Stk 2088)

Amada HFE M2 5020 Press Brake, 8 axis (Stk 2088)

Amada HFE M2 5020 8 axis Press Brake stk 2088 A

Amada HFE M2 5020 8 axis Press Brake stk 2088 F

Amada HFE M2 5020 8 axis Press Brake stk 2088 E

Amada HFE M2 5020 8 axis Press Brake stk 2088 D

Amada HFE M2 5020 8 axis Press Brake stk 2088 C

Amada HFE M2 5020 8 axis Press Brake stk 2088 B

FEATURES & BENEFITS

Warranty: Parts and labour warranty (UK). Installation and training available.
Availability: Ex stock.
Condition: Available to view in our Warehouse near Sandbach, Cheshire, UK. Jct17 M6.
Price: P.O.A

Share this Page

Amada HFE M2 5020 Press Brake, 8 axis (Stk 2088)

TECHNICAL SPECIFICATIONS

Amada HFE M2 5020 Press Brake, 8 axis (Stk 1978)

Model	Amada HFE M2 5020, 8 axis Press Brake
Year	2016
Tonnage	50 tonnes
Max. Bend Length	2090 mm
Standard Stroke	200 mm
Approach Speed	1-100 mm/sec
Bending Speed	1-10 mm/sec
Return Speed	1-100 mm/sec
Oil Capacity	55 L
Mains Voltage (V/Hz)	400/50
Weight	4850 Kg

Dimensions
Machine Length	2905 mm
Machine Width	1900 mm
Beam Width	60 mm

Table Height	960 mm
Machine Height	2450 mm
Open Height	470 mm
Throat Depth	100 mm
CNC Control Type	AB PAD Controller
Display	Interactive Touch Screen
Controlled Axis	8
