CoastOne C12 Electric Press Brake (Stk 1002)

Warranty: Parts and labour warranty (UK). Installation and training available.
Availability: Ex stock.
Condition: Available to view in our Warehouse near Sandbach, Cheshire, UK. Jct17 M6.
Price: P.O.A

Share this Page

Model	CoastOne C12 Press Brake. Electric (NEW)
Year	NEW
Tonnage	48 tonnes
Motor Power	2 x 5 kw
Maximum bending length	1300 mm
Distance between side frames	1250 mm
Frame width	1930 mm
Frame height	2150 mm
Frame depth	1550 mm
Throat depth	150 mm
Table height	820 mm
Weight	2800 kg
Daylight gap	500 mm
Y-axis stroke	250 mm
Y axis repeating accuracy	+/- 0.002 mm
Y axis max working speed	10mm or 20mm
Y axis approach speed	100 mm
Y axis return speed	100 mm
X axis speed	500 mm
X axis accuracy	+/- 0.025 mm
X axis stroke	600 mm
X axis max position dimension Delta X axis speed Delta X axis accuracy Delta X axis stroke R axis speed R axis accuracy R axis stroke Z axis speed Z axis accuracy Z axis stroke Control	750 mm 100 mm/s +/- 0.025 mm +/- 50mm 100 mm/s +/- 0.05 mm 200 mm 1000 mm/s +/- 0.5 mm 120 to 1180 mm Cone TC15 15″ touch screen Networkable control, offline storage and retrieval
Controlled Axis	3, 5 or 6 available
Note: Different model specifications available
